Home/ Light commercial/ LIO 140
EXEAT· EXLIO140· LIGHT COMMERCIAL

LIO 140

Up to 12 kg per batch

Up to 12 kg per day, touchscreen control, compact design, European-built, CE certified. High-capacity professional freeze dryer for labs and producers.

Indicative list price
€10.180
EX-VAT · CONFIGURATION-DEPENDENT
Configure quote Talk to an engineer →
Available configurations
LIO 140 (7 trays)LIO 140 L (10 trays)LIO 140 L with oil-free pump (10 trays)LIO 140 Pro (10 trays)LIO 140 Pro with oil-free pump (10 trays)LIO 140 with oil-free pump (7 trays)
LIO 140
Capacity
Up to 12 kg
Shelf area
1.5 m²
Trays
6
Shelf temp
-35 to +60 (recipe) °C
Condenser
-43 °C
Spec sheet

Engineering data.

Batch capacity (fresh load)
12 kg/batch
Ice condenser capacity
24 kg (total ice)
Total shelf area
1.5 m²
Number of shelves
6 count
Number of trays
6 count
Tray size
36.5 × 69.5 cm
Shelf temperature range
-35 to +60 (recipe) °C
Min. condenser temperature
-43 °C
Vacuum pump type
Oil-sealed (oil-free scroll option)
Refrigeration type
Air-cooled
Chamber material
AISI 304 stainless steel
Shelf material
Stainless steel
Body color options
Black
Defrosting
Manual (heated)
Control system
PLC touchscreen
Data logging & recipes
USB CSV export + recipes
Remote monitoring
No
External dimensions (W × D × H)
800 × 900 × 1205 mm
Net weight
295 kg
Power supply
400 V / 3~ / 50 Hz V / phase / Hz
Connected load
2.72 kW
Warranty
1 year + 8-year spares
Energy consumption (avg)
2.46 kWh/h
